AM-1024768J2TZQW-T00H

Avnet Embedded offers a complete portfolio of standard display modules as well as versions with high brightness, wide temperature range, wide viewing angles (IPS-Technology), sunlight readability, ruggedness and long-life backlights. The TFT displays, Memory in Pixel, Mini-LED displays and passive LCD modules are available with optical bonding, cover-glasses and different touch-technologies also.
We provide industrial, automotive or semi-consumer grades.

Specifications

LCD TypeTFT
Size8.00
Resolution1024 x 768
LCD I/FOpen LVDS
LCD Brightness [ cd/m²]1000
Min. Temp. [°C]-20
Max. Temp. [°C]++50
Aspect ratio4:3
Contrast1800:1
Touch I/FUSB
Coverlens Outline [length x width x depth in mm]172.00 x 128.90 x 1.10
Related driving boardTBD
MP dateJan 2019
ManufacturerAmpire
System brightness [ cd/m²]850
Mechanical Outline [length x width x depth in mm]83.43 x 138.35 x 3.75
Touch PcapY
Touch Resistiven
SpeakerN
IP RATINGN
Power INN
Mtbf hrs [khrs]30
