MSC C6B-CFLH

Intel® Core™ 8th Generation

The MSC C6B-CFLH module is based on the 8th Generation Intel^® Core™ Processor family. The Intel two-chip solution allows highest performance in graphics and computing on a COM Express module in basic form factor. The new MSC C6B-CFLH offers triple independent display support with up to 4k x 2k resolution, highest level graphics acceleration and hardware based video en-/decoding. Fast DDR4 memory with optional error correction (ECC) and multiple USB 3.1/2.0 interfaces complete the compact and powerful module. With choices of six and quad-core processor options the board is well positioned to address challenging performance demands. Besides an extensive set of interfaces and features, the MSC C6B-CFLH offers hardware based security compliant to the requirements of TCG (Trusted Computing Group). The Type 6 pin-out allows direct access to the latest digital display interfaces like DisplayPort 1.4, DisplayPort 1.2, HDMI 1.4 and DVI as well as up to four USB 3.1 interfaces supporting the fastest peripherals currently available.

Highlights

Intel^® Core™ i7-8850H (six-core, 2.6/4.3GHz, 45/35W cTDP),
Intel^® Core™ i5-8400H (quad-core, 2.5/4.2GHz, 45/35W cTDP)
Intel^® Core™ i3-8100H (quad-core, 3.0GHz, 45/35W cTDP)
Intel^® Xeon^® E-2176M (six-core, 2.7/4.4GHz, 45/35W cTDP),
Intel^® UHD Graphics
Intel^® chipsets QM370 or CM246
Up to 32GB DDR4-2666 SDRAM, dual channel (ECC optionally supported on models with Xeon E-2176M)
Four SATA 6Gb/s mass storage interfaces
Three DisplayPort/HDMI/DVI interfaces

Embedded DisplayPort / LVDS (24 Bit, dual channel) interface
Triple independent display support
DirectX 12, OpenGL 4.5, OpenCL 2.x
Resolution up to 4096 x 2304
Eight PCI Express™ x1 lanes, configurable up to x4, Intel^® Rapid Storage Technology support
PEG configurable as 1×16 or 2×8 or 1×8 + 2×4
Four USB 3.1/2.0 and four USB 2.0 interfaces
Trusted Platform Module
UEFI Firmware

Specs

Technology	x86
Formfactor	COM Express Basic
CPU	Intel® Core™ i7-8850H (six-core, 2.6/4.3GHz, 9M cache, 45/35W cTDP), Intel® Core™ i5-8400H (quad-core, 2.5/4.2GHz, 8M cache, 45/35W cTDP), Intel® Core™ i3-8100H (quad-core, 3.0GHz, 6M cache, 45/35W cTDP), Intel® Xeon® E-2176M (six-core, 2.7/4.4GHz, 12M cache, 45/35W cTDP), Intel® Technologies: Intel® vPro, Intel® 64, Intel® Virtualization Technology (VT-x), Intel® Virtualization Technology for Directed I/O (VT-d), Intel® Trusted Execution Technology, Intel® Adv. Encryption Standard AES-NI, Intel®Turbo Boost Technology 2.0 not on all models
Chipset	Intel® Platform Controller Hubs (PCH) QM370 or CM246
RAM	2x 260-pin SO-DIMM socket for up to 2x 16GB DDR4 SDRAM (DDR4-2666¹); dual channel operation; ECC option¹² ¹ Depending on SO-DIMM type ² ECC supported on models with Xeon E-2176M
Storage Interfaces	4x SATA channels (up to 6Gb/s)
USB	4x USB 3.1 (Gen 1 & 2)/2.0, 4x USB 2.0
Serial Interfaces	2x high-speed serial ports from PCH
Bus Interfaces	8x PCI Express x1 Gen 3, 1x PCI Express Graphics (PEG) x 16 Gen. 3 LPC bus (Low Pin Count bus; no DMA support)
Display Controller	Integrated Intel UHD graphics Gen. 9 3D Acceleration: DirectX® 11/12, OpenGL 4.3/4.4, OpenGL ES 2.0, OpenCL 2.x; HW accelerated Video Decode: H.264/AVC, VP8, VP9, VP9 10 Bit, H.265/HEVC 8 bit, H.265/HEVC 10 Bit, MPEG2, MJPEG, VC-1 HW accelerated Video Encode: H.264/AVC, VP8, VP9, H.265/HEVC 8 bit, H.265/HEVC 10 Bit, MPEG2, MJPEG. Triple independent display support
Display Interfaces	Display Port and HDMI/DVI: 3x Digital Display Interface, usable as DisplayPort 1.2 (up to 4096 x 2304 @ 60Hz), also usable as HDMI 1.4b or DVI (up to 4096 x 2160 @ 30Hz) 1x Embedded DisplayPort 1.4 (on variants without LVDS only); 4096 x 2304 @ 60Hz LCD: LVDS 24bit, dual-channel (not on all variants); 1920 x 1200 @ 60Hz
Network Interface	10/100/1000Base-TX (integrated in PCH, Intel® i219LM PHY)
Audio Interface	High Definition Audio
Security Device	TPM 2.0
Miscellaneous	Watchdog Timer: Initiates system reset, programmable Fan Supply: 4-pin header for 12V CPU fan, PWM speed controlled and PWM speed control for system fan supported RTC battery: External System Monitoring: Voltage, temperature, CPU fan, system fan
Firmware	UEFI Firmware: AMI Aptio® V Security: TPM 2.0 support, TCG compliant Power Management: ACPI Active fan control USB: USB legacy support (keyboard, mouse, storage) Monitoring: System Monitoring Health Monitoring MSC Adv. Boot Device Selection: Boot device priority setting based on physical interfaces
OS Support	Windows 10 IOT Enterprise BSP for Linux (Yocto) EAPI (HW Programming Interface)
Power Requirement	Voltage: +8.5V to +20V, +5V Stby optional Power Consumption: 35 W to 55 W (typ.)
Environment	Ambient Temperature; 0° … 60°C (operating), -25° … 85°C (storage) Humidity: 5 … 95% (operating, non-condensing), 5 … 95% (storage, non-condensing)
Dimensions	125mm x 95mm x 13mm* (*Measured from module PCB bottom side to heat spreader top side. Different heights apply, when using other cooling solutions.)
Certificates	UL / CE

Order Info

Order No.	Description	Reference	Status
73872	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Xeon E-2176M, six-core, 2.7/4.4GHz, 45W TDP; Chipset: CM246; Graphics: integrated Intel HD Gen 9 (GT2); Embedded DisplayPort (eDP); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 or DDR4 ECC SO-DIMM; TPM 2.0.	MSC C6B-CFLH-2176M-NN1101C PCBFTX	OR
73874	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Xeon E-2176M, six-core, 2.7/4.4GHz, 45W TDP; Chipset: CM246; Graphics: integrated Intel HD Gen 9 (GT2); LVDS (24 Bit, dual channel); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 or DDR4 ECC SO-DIMM; TPM 2.0.	MSC C6B-CFLH-2176M-NN1201C PCBFTX	OR
73848	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i7-8850H, six-core, 2.6/4.3GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); Embedded DisplayPort (eDP); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8850H-NN0101C PCBFTX	PV
73850	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i7-8850H, six-core, 2.6/4.3GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); LVDS (24 Bit, dual channel); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8850H-NN0201C PCBFTX	PV
73876	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i5-8400H, quad-core, 2.5/4.2GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); Embedded DisplayPort (eDP); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8400H-NN0101C PCBFTX	PV
73878	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i5-8400H, quad-core, 2.5/4.2GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); LVDS (24 Bit, dual channel); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8400H-NN0201C PCBFTX	PV
76724	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i3-8100H, quad-core, 3.0GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); Embedded DisplayPort (eDP); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8100H-NN0101C PCBFTX	PV
76728	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i3-8100H, quad-core, 3.0GHz, 45W TDP; Chipset: CM246; Graphics: integrated Intel HD Gen 9 (GT2); Embedded DisplayPort (eDP); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 or DDR4 ECC SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8100H-NN1101C PCBFTX	OR
76726	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i3-8100H, quad-core, 3.0GHz, 45W TDP; Chipset: QM370; Graphics: integrated Intel HD Gen 9 (GT2); LVDS (24 Bit, dual channel); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8100H-NN0201C PCBFTX	PV
76730	COM Express Type 6 Basic module (125mm x 95mm); CPU: Intel Core i3-8100H, quad-core, 3.0GHz, 45W TDP; Chipset: CM246; Graphics: integrated Intel HD Gen 9 (GT2); LVDS (24 Bit, dual channel); 3x DP/HDMI/DVI; Ethernet: Intel i219 Gbit; HD audio; 4x SATA; 4x USB3.1/2, 4x USB2; 8x PCIe x1 Gen 3; PEG x16 Gen 3; 2x socket for DDR4 or DDR4 ECC SO-DIMM; TPM 2.0.	MSC C6B-CFLH-8100H-NN1201C PCBFTX	OR

PV = Preferred variant; OR = on Request (in OEM quantities only)

Accessories

Carrier Options

Order No.	Description	Reference
67295	COM Express Type 6 Evaluation Carrier Board with PCI Express x4/x16 slot, USB 3.0/2.0, GbE, SATA, DisplayPort, eDP/LVDS, VGA and HD audio interfaces; Mini PCI Express socket, SD card slot, ATX power connector and single 12V power jack. Dimensions: 170mm x 170mm (Mini-ITX form factor)	MSC C6-MB-EV-001 PCBFTX
41857	COM Express Type 6 Evaluation Carrier Board with various PCI Express x1, x4 and x16 slots, USB 3.0/2.0, GbE, SATA, DisplayPort, HDMI, LVDS, eDP, VGA, HD audio interfaces; mSATA and Mini PCI Express sockets, POST code display, ATX power connector. Dimensions: 305 x 244 mm (ATX form factor)	MSC C6-MB-EVA PCBFTX

Cooling Options

Order No.	Description	Reference
1131080	Active Heatsink for C6B-SLH, C6B-KLH, C6B-CFLH and C6B-CFLR, consisting of a single-piece aluminum profile with fins, pressed in standoffs without thread (2.7mm inner diameter), screws and thermopads for the thermal contact to CPU and chipset. PWM fan 80x80x15mm.	MSC C6B-SLH-01 HSF-001
1131081	Passive Heatsink for C6B-SLH, C6B-KLH, C6B-CFLH and C6B-CFLR, consisting of a single-piece aluminum profile with fins, pressed in standoffs without thread (2.7mm inner diameter), screws and thermopads for the thermal contact to CPU and chipset.	MSC C6B-SLH-01 HSI-001
1131082	Heatspreader for C6B-SLH, C6B-KLH, C6B-CFLH and C6B-CFLR. Single-piece aluminum profile, pressed in standoffs without thread (2.7mm inner diameter), screws and thermopads for the thermal contact to CPU and chipset. No fan, no SO-DIMM cutout.	MSC C6B-SLH-01 HSP-001
1131083	Heatspreader for C6B-SLH, C6B-KLH, C6B-CFLH and C6B-CFLR. Single-piece aluminum profile, pressed in standoffs with M2.5 thread, screws and thermopads for the thermal contact to CPU and chipset. No fan, no SO-DIMM cutout.	MSC C6B-SLH-02 HSP-001

Memory Options

Order No.	Description	Reference
95549	16GB DDR4-2666 SO-DIMM, ECC	MOD SODIMM DDR4 16GB PC4-21300 CL19 2B
84495	16GB DDR4-2666 SO-DIMM	MOD SODIMM DDR4 16GB PC4-21300 CL19 2B
82970	32GB DDR4 2666 SO-DIMM	MOD SODIMM DDR4 32GB PC4-21300 CL19 2B
83004	4GB DDR4-2666 SO-DIMM, ECC	MOD SODIMM DDR4 4GB PC4-21300 CL19 1B
78199	4GB DDR4 2666 SO-DIMM	MOD SODIMM DDR4 4GB PC4-21300 CL19 1B
80263	8GB DDR4 2666 SO-DIMM	MOD SODIMM DDR4 8GB PC4-21300 CL19 1B
95546	8GB DDR4-2666 SO-DIMM, ECC	MOD SODIMM DDR4 8GB PC4-21300 CL19 1B

Starter Kits

Order No.	Description	Reference
78252	Starterkit for COM Express Type 6 modules with Intel 8th or 9th generation Core processors (Coffee Lake H, Coffee Lake Refresh). Consists of the MSC C6-MB-EV Mini-ITX platform board, suitable Heatsink with fan, two memory modules and a suitable power supply with cable kit. Please order separately the COM Express C6B-CFLH or C6B-CFLR module of your choice.	MSC C6-SK-CFLH-EV-KIT001

Support

Manual

MSC_C6B-CFLH_C6B-CFLR_User-Manual

Last update: 18/01/2023 2.66 MB

Download

msc-ldk-bsp-CoffeeLake-v1.9.0-20220801

Last update: 10/08/2022 1.19 MB

MSC_C6B-SLH_C6B-KLH_C6B-CFLH_C6B-CFLR-Heatsink_Montage_V05

Last update: 29/12/2022 971 KB

MSC_C6B-SLH_C6B-KLH_C6B-CFLH_C6B-CFLR-Heatspreader_Montage_V05

Last update: 29/12/2022 798 KB

Application Notes

App_Note_002_EDID_File_generation

Last update: 29/12/2022 292.49 KB

App_Note_013_COMe_T6_Carrier-Board_Recommendations

Last update: 29/12/2022 429.78 KB

App_Note_017_OS_Boot_support_for_different_media

Last update: 29/12/2022 147.99 KB

App_Note_019_Activate_screen_after_WoL_from_sleep

Last update: 29/12/2022 243.99 KB

App_Note_021_Install_Win7_on_Recent_Intel_Architectures

Last update: 29/12/2022 635.75 KB

App_Note_022_MSC_BIOS_Configurator_Tool

Last update: 29/12/2022 513.83 KB

App_Note_028_MSC_AutoFLASH

Last update: 22/03/2023 357 KB

App_Note_030_Building_from_MSC_Git_V1_9

Last update: 05/10/2023 482.45 KB

App_Note_030_Addendum_Building_from_MSC_Git_2023-10-23

Last update: 23/10/2023 396.15 KB

App_Note_032_Secure_Boot

Last update: 29/12/2022 332.92 KB

Compliance documents

China-ROHS-Statement_MSC_COM_Express_2023-10

Last update: 16/10/2023 140.36 KB

REACH-ROHS-Statement_MSC_COM_Express_2023-10

Last update: 16/10/2023 119.48 KB

Mechanical data

MSC_Mechanical_3D_information-AVE

Last update: 11/12/2023 213 KB

MSC_C6B-CFLH_3D

Last update: 29/12/2022 24.65 MB

MSC_C6B-SLH_C6B-KLH_C6B-CFLH_C6B-CFLR-01_HSF-001_3D

Last update: 29/12/2022 19.73 MB

MSC_C6B-SLH_C6B-KLH_C6B-CFLH_C6B-CFLR-01_HSI-001_3D

Last update: 29/12/2022 18.33 MB

MSC_C6B-SLH_C6B-KLH_C6B-CFLH_C6B-CFLR-01_HSP-001_3D

Last update: 29/12/2022 17.83 MB

BIOS

Download

MSC_BIOS-Configurator-Tool

Last update: 22/03/2023 205.83 KB

App_Note_028_MSC_AutoFLASH

Last update: 22/03/2023 357 KB

BIOS_PostCodes_AMI-UEFI_Aptio_5.x_PUB

Last update: 22/03/2023 280 KB

BIOS_Update_C6B-CFLH_C6B-CFLR_BIOS_V240_01

Last update: 26/05/2023 85.47 MB

BIOS_Update_C6B-CFLH_C6B-CFLR_BIOS_V250_01

Last update: 02/04/2024 157.59 MB

Drivers

Win 10-64bit

Graphics_win64

Last update: 29/12/2022 339.51 MB

MSCHSUart_V112_01

Last update: 28/04/2023 234.75 KB

PROWinx64

Last update: 29/12/2022 78 MB

chipset-10.1.17968.8131-public-mup

Last update: 29/12/2022 5.36 MB

intel(r) csme_corporate_12.0.34.1425

Last update: 29/12/2022 619 MB

rst_17.5.0.1011

Last update: 29/12/2022 240.95 MB

serialio_30.100.1902.3_cnl-pch_rs5

Last update: 29/12/2022 1.03 MB

Demo Images

Download

msc-image-base-intel-corei7-64_master_20072023

Last update: 20/07/2023 1,231.90 MB

Download

msc-image-lxqt-intel-corei7-64_master_20072023

Last update: 20/07/2023 2,499.33 MB

PCN - EOL - Product Information (Login to see this section)

MSC EAPI NG for modules with AMI BIOS

MSC EAPI WinXP Win7 Win10 x86 x64

MSC EAPI v321_02

Last update: 22/03/2023 17 MB

MSC EAPI Linux

App_Note_023_Building_EAPI_and_MscIo_from_GIT_(32bit_and_64bit)_281117

Last update: 22/03/2023 11 KB
